Productivity 1000

...STACKABLE MICRO PLC

The Productivity1000 range is ideal for small to medium sized projects. Housed in a smaller and slimmer design, the P1000 will deliver the time, space and budget savings for many of today's industrial automation projects.

- Micro Form Factor - Tag based addressing - Ethernet connectivity - Free Software

SHOP
PRODUCT INFO

Product Code	Product Name	Price ($AUD)
Product Code : P1-RX	Productivity1000 remote I/O module - Productivity1000 remote I/O module, 1 port, (1) Ethernet (RJ45) port(s). For use with P1-550 or P2-550 CPUs. Requires Productivity1000 (P1-550) or Productivity2000 (P2-5_{… (read more)}	$201.00
Product Code : P1-15TD2	Productivity1000 discrete output module - Productivity1000 discrete output module, 15-point, 12-24 VDC, sourcing, 1 common(s), 15 point(s) per common, 1A/point. Requires P2-RTB or P2-RTB-1 removable terminal bloc_{… (read more)}	$137.00
Product Code : P1-15TD1	Productivity1000 discrete output module - Productivity1000 discrete output module, 15-point, 3.3-24 VDC, sinking, 2 common(s), 8 point(s) per common, 1A/point. Requires P2-RTB or P2-RTB-1 removable terminal block_{… (read more)}	$137.00
Product Code : P1-08TA	Productivity1000 discrete output module - Productivity1000 discrete output module, 8-point, 120-240 VAC, 2 isolated common(s), 4 point(s) per common, 0.5A/point, 4A/common. Requires P1-10RTB or P1-10RTB-1 removab_{… (read more)}	$207.00
Product Code : P1-16TR	Productivity1000 relay output module - Productivity1000 relay output module, 16-point, 6-24 VDC/6-120VAC, (16) Form A, 2 common(s), 8 point(s) per common, 2A/point, 8A/common. Requires P2-RTB or P2-RTB-1 remov_{… (read more)}	$195.00
Product Code : P1-08TD1	Productivity1000 discrete output module - Productivity1000 discrete output module, 8-point, 3.3-24 VDC, sinking, 1 common(s), 8 point(s) per common, 1A/point. Requires P1-10RTB or P1-10RTB-1 removable terminal bl_{… (read more)}	$92.00
Product Code : P1-16CDR	Productivity1000 discrete relay combo module - Productivity1000 discrete relay combo module, Input: 8-point, 24 VAC/VDC, sinking/sourcing, Output: 8-point, 6-24 VDC/6-120 VAC, relay, (8) Form A (SPST) relays, 1A/point_{… (read more)}	$204.00
Product Code : P1-15CDD1	Productivity1000 discrete combo module - Productivity1000 discrete combo module, Input: 8-point, 12-24 VDC, sinking/sourcing, Output: 7-point, 3.3-24 VDC, sinking, 1A/point. Requires P2-RTB or P2-RTB-1 removable_{… (read more)}	$157.00
Product Code : P1-04ADL-1	Productivity1000 analog input module - Productivity1000 analog input module, 4-channel, current, 13-bit, input current signal range(s) of 0-20 mA, external 24 VDC required. Requires P1-10RTB or P1-10RTB-1_{… (read more)}	$175.00
Product Code : P1-04AD-2	Productivity1000 analog input module - Productivity1000 analog input module, 4-channel, voltage, 16-bit, input voltage signal range(s) of 0-10 VDC, external 24 VDC required.	$268.00
Product Code : P1-4ADL2DAL-1	Productivity1000 analog combo module - Productivity1000 analog combo module, Input: 4-channel, current, 0-20 mA, Output: 2-channel, current, 4-20 mA. Requires P1-10RTB or P1-10RTB-1 removable terminal block or_{… (read more)}	$293.00
Product Code : P1-04RTD	Productivity1000 temperature input module - Productivity1000 temperature input module, RTD, 4-channel, 16-bit resolution, input RTD type(s): Pt100, Pt1000, JPt100, Cu10, Cu25 and Ni120. (1) P1-10RTB screw terminal _{… (read more)}	$293.00
Product Code : P1-04NTC	Productivity1000 temperature input module - Productivity1000 temperature input module, thermistor, 4-channel, 16-bit resolution, input thermistor type(s): 2252, 10K-AN Type 3, 10K-CP Type 2, 5K, 3K and 1.8K ohm. (1_{… (read more)}	$317.00
Product Code : P1-04ADL-2	Productivity1000 analog input module - Productivity1000 analog input module, 4-channel, voltage, 13-bit, input voltage signal range(s) of 0-10 VDC, external 24 VDC required. Requires P1-10RTB or P1-10RTB-_{… (read more)}	$175.00
Product Code : P1-04DAL-2	Productivity1000 analog output module - Productivity1000 analog output module, 4-channel, voltage, 12-bit, output voltage signal range(s) of 0-10 VDC, external 24 VDC required. Requires P1-10RTB or P1-10RT_{… (read more)}	$218.00
Product Code : P1-04DAL-1	Productivity1000 analog output module - Productivity1000 analog output module, 4-channel, current, 12-bit, output current signal range(s) of 4-20 mA, external 24 VDC required. Requires P1-10RTB or P1-10RTB_{… (read more)}	$247.00
Product Code : P1-04THM	Productivity1000 temperature input module - Productivity1000 temperature input module, thermocouple, 4-channel, 16-bit resolution, input thermocouple type(s): J, E, K, R, S, T, B, N, C. (1) P1-10RTB screw terminal _{… (read more)}	$317.00
Product Code : P1-08SIM	Productivity1000 simulator input module - Productivity1000 simulator input module, 8-point.	$97.00
Product Code : P1-04AD	Productivity1000 analog input module - Productivity1000 analog input module, 4-channel, current/voltage, 16-bit, input current signal range(s) of 0-20 mA, input voltage signal range(s) of 0-5 VDC, 0-10 VDC, +/_{… (read more)}	$411.00
Product Code : P1-04AD-1	Productivity1000 analog input module - Productivity1000 analog input module, 4-channel, current, 16-bit, input current signal range(s) of 0-20 mA, external 24 VDC required.	$280.00
Product Code : P1-08ADL-1	Productivity1000 analog input module - Productivity1000 analog input module, 8-channel, current, 13-bit, input current signal range(s) of 0-20 mA, external 24 VDC required. Requires P1-10RTB or P1-10RTB-1_{… (read more)}	$235.00
Product Code : P1-08ADL-2	Productivity1000 analog input module - Productivity1000 analog input module, 8-channel, voltage, 13-bit, input voltage signal range(s) of 0-10 VDC, external 24 VDC required. Requires P1-10RTB or P1-10RTB-_{… (read more)}	$235.00
Product Code : P1-08DAL-1	Productivity1000 analog output module - Productivity1000 analog output module, 8-channel, current, 12-bit, output current signal range(s) of 4-20 mA, external 24 VDC required. Requires P1-10RTB or P1-10RTB_{… (read more)}	$311.00
Product Code : P1-08DAL-2	Productivity1000 analog output module - Productivity1000 analog output module, 8-channel, voltage, 12-bit, output voltage signal range(s) of 0-10 VDC, external 24 VDC required. Requires P1-10RTB or P1-10RT_{… (read more)}	$284.00
Product Code : P1-4ADL2DAL-2	Productivity1000 analog combo module - Productivity1000 analog combo module, Input: 4-channel, voltage, 0-10 VDC, Output: 2-channel, voltage, 0-10 VDC. Requires P1-10RTB or P1-10RTB-1 removable terminal block _{… (read more)}	$274.00
Product Code : P1-540	Productivity1000 CPU - Productivity1000 CPU, up to 50 MB ladder memory, microSD card slot, (1) Ethernet 10/100Base-T (RJ45), (1) RS-232 (RJ12), (1) RS-485 (4-pin terminal) and (1) microB-USB po_{… (read more)}	$444.00
Product Code : P1-550	Productivity1000 CPU - Productivity1000 CPU, up to 50 MB ladder memory, microSD card slot, (2) Ethernet 10/100Base-T (RJ45), (1) RS-232 (RJ12), (1) RS-485 (4-pin terminal) and (1) microB-USB po_{… (read more)}	$499.00
Product Code : P1-01AC	Productivity1000 AC/DC power supply - Productivity1000 AC/DC power supply, 120-240 VAC or 125 VDC nominal input. External power supply optional.	$103.00
Product Code : P1-02AC	Productivity1000 AC Power Supply - Productivity1000 AC power supply, 120-240 VAC or 125 VDC nominal input. External power supply optional. For applications exceeding (8) P1000 modules.	$131.00
Product Code : P1-01DC	Productivity1000 DC Power Supply - Productivity1000 DC power supply, 12-24 VDC nominal input. External power supply optional. For applications not exceeding (8) P1000 modules.	$121.00
Product Code : P1-08NA	Productivity1000 discrete input module - Productivity1000 discrete input module, 8-point, 120-240 VAC, 2 isolated common(s), 4 point(s) per common. Requires P1-10RTB or P1-10RTB-1 removable terminal block or ZIP_{… (read more)}	$166.00
Product Code : P1-08ND3	Productivity1000 discrete input module - Productivity1000 discrete input module, 8-point, 12-24 VDC, sinking/sourcing, 2 common(s), 4 point(s) per common. Requires P1-10RTB or P1-10RTB-1 removable terminal block_{… (read more)}	$91.00
Product Code : P1-08NE3	Productivity1000 discrete input module - Productivity1000 discrete input module, 8-point, 24 VAC/VDC, sinking/sourcing, 2 isolated common(s), 4 point(s) per common. Requires P1-10RTB or P1-10RTB-1 removable term_{… (read more)}	$91.00
Product Code : P1-16ND3	Productivity1000 discrete input module - Productivity1000 discrete input module, 16-point, 12-24 VDC, sinking/sourcing, 2 isolated common(s), 8 point(s) per common. Requires P2-RTB or P2-RTB-1 removable terminal_{… (read more)}	$144.00
Product Code : P1-16NE3	Productivity1000 discrete input module - Productivity1000 discrete input module, 16-point, 24 VAC/VDC, sinking/sourcing, 2 isolated common(s), 8 point(s) per common. Requires P2-RTB or P2-RTB-1 removable termina_{… (read more)}	$144.00
Product Code : P1-08TD2	Productivity1000 discrete output module - Productivity1000 discrete output module, 8-point, 12-24 VDC, sourcing, 1 common(s), 8 point(s) per common, 1A/point. Requires P1-10RTB or P1-10RTB-1 removable terminal bl_{… (read more)}	$89.00
Product Code : P1-08TRS	Productivity1000 relay output module - Productivity1000 relay output module, 8-point, 6-24 VDC/6-120 VAC, (6) Form A, (2) Form C, 8 common(s), 8 isolated common(s), 1 point(s) per common, 3A/point. Requires P2_{… (read more)}	$113.00
Product Code : P1-15CDD2	Productivity1000 discrete combo module - Productivity1000 discrete combo module, Input: 8-point, 12-24 VDC, sinking/sourcing, Output: 7-point, 12-24 VDC, sourcing, 1A/point. Requires P2-RTB or P2-RTB-1 removable_{… (read more)}	$155.00
Product Code : P1-02HSC	Productivity1000 high-speed pulse input module - Productivity1000 high-speed pulse input module, 100 kHz maximum switching frequency, 2-channel, 2 general purpose input points, sinking/sourcing, 2 common(s). Requir_{… (read more)}	$167.00
Product Code : P1-04PWM	Productivity1000 high-speed pulse width modulation output module - Productivity1000 high-speed pulse width modulation output module, 8-point, 4-channel, 5-24 VDC, sinking/sourcing, external 5-24 VDC required. Requires P1-10RTB or P1_{… (read more)}	$178.00
Product Code : PCON-KIT	Connector kit, replacement. - Connector kit, replacement. For use with Productivity Series modules. Includes (1) P3-RS485CON 3-wire connector, (1) P3-RS485CON-1 4-wire connector and (1) Productivity10_{… (read more)}	$21.00
Product Code : P1-10RTB	Productivity1000 terminal block - Productivity1000 terminal block, 10-pin screw type. For use with Productivity1000 I/O modules.	$16.00
Product Code : P1-10RTB-1	Productivity1000 terminal block - Productivity1000 terminal block, 10-pin spring clamp. For use with Productivity1000 I/O modules.	$16.00
Product Code : P1-USER-M	Productivity1000 user manual - Download only - Productivity1000 user manual This is a downloadable product only. You can download it with the following link: Download User Manual	$0.00
Product Code : ZL-P1-CBL10	ZIPLink PLC I/O cable - ZIPLink PLC I/O cable, 10-position terminal block to 24-pin connector, 90-degree connector angle, 1.6ft/0.5m cable length. For use with Productivity1000 I/O modules.	$51.00
Product Code : ZL-P1-CBL10-1	ZIPLink PLC I/O cable - ZIPLink PLC I/O cable, 10-position terminal block to 24-pin connector, 90-degree connector angle, 3.2ft/1m cable length. For use with Productivity1000 I/O modules.	$52.00
Product Code : ZL-P1-CBL10-1P	ZIPLink PLC I/O cable - ZIPLink PLC I/O cable, 10-position terminal block to pigtail, 90-degree connector angle, 3.2ft/1m cable length. For use with Productivity1000 I/O modules.	$42.00
Product Code : ZL-P1-CBL10-2	ZIPLink PLC I/O cable - ZIPLink PLC I/O cable, 10-position terminal block to 24-pin connector, 90-degree connector angle, 6.5ft/2m cable length. For use with Productivity1000 I/O modules.	$63.00
Product Code : ZL-P1-CBL10-2P	ZIPLink PLC I/O cable - ZIPLink PLC I/O cable, 10-position terminal block to pigtail, 90-degree connector angle, 6.5ft/2m cable length. For use with Productivity1000 I/O modules.	$48.00
Product Code : ZL-P1-CBL18	ZIPLink PLC I/O cable - ZIPLink PLC I/O cable, 18-position terminal block to 24-pin connector, 90-degree connector angle, 1.6ft/0.5m cable length. For use with Productivity1000 I/O modules.	$63.00

Productivity1000® Stackable Micro Programmable Controller

Features

Memory: up to 50 MB total available user memory
Programming language: Ladder logic
Dimensions: approx 32.8mm x 77.4mm
Maximum I/O Capacity: 240
Communications: 4 or 5 comms ports including Ethernet port

Advanced instructions and task management
Real Time Clock/Calendar
Battery for memory retention
Hardware auto-discovery
Supports a maximum of 15 I/O modules for a total of 240 discrete I/O
2 Serial communications ports: both supporting Modbus RTU and ASCII In/Out up to 115.2K baud rate
1 Ethernet port:  (10/100Mbps Ethernet) Programming, Monitoring, Debug, Firmware, Email SMTP Client, Modbus TCP Client, Ethernet / IP Scanner and Adapter, Custom Protocol over Ethernet, ProNet.
1 x Ethernet port (Remote I/O): (P1-550 only)
1 x Micro USB communication port: Programming, Monitoring, Debug, Firmware
Tag database and program documentation storage in CPU
Support for EtherNet/IP devices
Data logging up to 32GB on a MicroSD card (MicroSD sold separately)
Choose I/O wiring needs from spring clamp, screw terminal or the popular ZipLink wiring solution
Free Software "Productivity Suite"

Documentation

(AutomationDirect website) For current $AU please refer to our online store

Productivity 1000 Overview
Productivity Suite Overview

Complimentary Products

The P1000 CPUs are often paired with these products.

p1-16nd3-product-image

P1-16ND3

(16 Bit Digital Input Module)

12-24 VDC, sinking/sourcing, 2 isolated common(s), 8 point(s) per common. Requires P2-RTB or P2-RTB-1 removable terminal block or ZIPLink pre-wired cables.

P1-08TD2

(8 Bit Digital Output Module)

12-24 VDC, sourcing, 1 common(s), 8 point(s) per common, 1A/point. Requires P1-10RTB or P1-10RTB-1 removable terminal block or ZIPLink pre-wired cables.

P1-04THM

(4 Channel Thermocouple Input Module)

12-24 VDC, sourcing, 1 common(s), 8 point(s) per common, 1A/point. Requires P1-10RTB or P1-10RTB-1 removable terminal block or ZIPLink pre-wired cables.

P1-15CDD2

(Combo Digital I/O Module)

Input: 8-point, 12-24 VDC, sinking/sourcing, Output: 7-point, 12-24 VDC, sourcing, 1A/point. Requires P2-RTB or P2-RTB-1 removable terminal block or ZIPLink pre-wired cables.

P1-04ADL-1

(Analog Input Module)

4-channel, current, 13-bit, input current signal range(s) of 0-20 mA, external 24 VDC required.

Spare Parts & Specialty Items

10 & 18-pin screw type terminal blocks
10 & 18-pin spring clamp terminal blocks
MICSD-16G Micro SD memory card

ZipLink Wiring Solutions

The ZIPLink connection module and cable system eliminates the normally tedious process of wiring programmable controller I/O to terminal blocks.

Prewired cable

programming-software-cables

Free Programming Software

PS-PGMSW ProductivitySuite P1000

productivity1000-manual

Productivity1000 Documentation

P1-USER-M Hardware user manual

CPU and I/O module installation and wiring, specifications, troubleshooting.

Programming Software Highlights

User defined tag-based programming for descriptive I/O naming
Simple-to-use instructions and Easy Math to eliminate complex ladder logic
Tools for quick access to setup, programming, debugging and control
Task Manager for quick and easy prioritization of Ladder Logic code
Structured data types
Task management
Advanced "fill-in-the-blank" instructions
Seamless database connectivity
Graphical HTML-based Help File
Run-time editing
Project file and user documentation stored in CPU
MicroSD card slot on the CPU for data logging
Tag database import to C-more HMI
All in an intuitive Windows-based programming environment

Information courtesy of AutomationDirect

Last updated MARCH 2023. This publication may contain references to products produced and/or offered by other companies. The product and company names may be trademarked and are the sole property of their respective owners. Direct Automation Pty Ltd disclaims any proprietary interest in the marks and names of others. All prices shown are trade prices and are exclusive of GST. Prices are subject to change, orders will be accepted at the pricing ruling at the time of our acceptance of orders. Please refer to our online store for current $AU pricelist. Images for display purposes only and may be generic. Whilst all efforts to make information current and accurate, specifications are subject to change without notice. Always consult supplier and manufacture documents for current details.
