Productivity 3000

... HIGH PERFORMANCE - MODULAR PROGRAMMABLE CONTROLLER

The Productivity3000 is a robust, rack-based PLC that provides the expansive I/O, communication, and processing power needed for complex automation systems. With numerous networking options built in and a wide range of discrete, analog and motion modules, the P3000 series is a high-performance system built to scale with your most demanding applications.

SHOP
PRODUCT INFO

Product Code	Product Name	Price ($AUD)
Product Code : P3-03B	P3-03B 3 Slot Base - 3-slot local / expansion / remote base, P3-01AC or P3-01DC power supply required, holds 3 I/O modules (CPU, -EX or -RS does NOT consume a slot)	$464.00
Product Code : P3-05B	P3-05B 5 Slot Base - 5-slot local / expansion / remote base, P3-01AC or P3-01DC power supply required, holds 5 I/O modules (CPU, -EX or -RS does NOT consume a slot)	$549.00
Product Code : P3-08B	P3-08B 8 Slot Base - 8-slot local / expansion / remote base, P3-01AC or P3-01DC power supply required, holds 8 I/O modules (CPU, -EX or -RS does NOT consume a slot)	$692.00
Product Code : P3-11B	P3-11B 11 Slot Base - 11-slot local / expansion / remote base, P3-01AC or P3-01DC power supply required, holds 11 I/O modules (CPU, -EX or -RS does NOT consume a slot)	$822.00
Product Code : P3-01AC	P3-01AC Power Supply100-240VAC - Productivity3000 100-240 VAC base power supply unit (one AC or DC power supply required per base)	$444.00
Product Code : P3-01DC	P3-01DC Power Supply24-48VDC - Productivity3000 24-48 VDC base power supply unit (one AC or DC power supply required per base)	$466.00
Product Code : P3-08TRS-1	8-point 6-24VDC 6-240VAC - 8-point, 6-24 VDC / 6-240 VAC isolated relay output module, 5.0A / point @ 60 deg C, 8 commons (isolated), 1 point / common, with 4 Form C relays and 4 Form A relays. Req_{… (read more)}	$378.00
Product Code : P3-16DA-2	16-channel Voltage Analog Out - 16-channel voltage analog output module, 16-bit resolution, +/-10 VDC, external 24 VDC required. Requires removable terminal block (sold separately, P3-RTB); optional ZIP_{… (read more)}	$1,683.00
Product Code : P3-16AD-1	16-channel Sinking analog inpu - 16-channel current sinking analog input module, 16-bit resolution, 0-20 mA, external 24 VDC required. Requires removable terminal block (sold separately, P3-RTB); optiona_{… (read more)}	$1,001.00
Product Code : P3-16AD-2	16-channel Voltage analog inpu - 16-channel voltage analog input module, 16-bit resolution, 0-10 VDC, external 24 VDC required. Requires removable terminal block (sold separately, P3-RTB); optional ZIPLi_{… (read more)}	$978.00
Product Code : P3-16DA-1	16-channel current sourcingOut - 16-channel current sourcing analog output module, 16-bit resolution 4-20 mA, external 24 VDC required. Requires removable terminal block (sold separately, P3-RTB); option_{… (read more)}	$1,716.00
Product Code : P3-04DA	4-channel Volt or Curr output - 4-channel voltage or current analog output module, 16-bit resolution, signal ranges of +/-10 VDC and 4-20 mA, external 24 VDC required. Requires removable terminal block _{… (read more)}	$843.00
Product Code : P3-08AD	8-channel volt/curr analog in - 8-channel voltage/current analog input module, 16-bit resolution, software selectable signal ranges of: +/- 10 VDC, +/- 5 VDC, 0-5 VDC, 0-10 VDC and 0-20 mA, external 24 _{… (read more)}	$741.00
Product Code : P3-08DA-1	8-channel Sourcing output - 8-channel current sourcing analog output module, 16-bit resolution 4-20 mA, external 24 VDC required. Requires removable terminal block (sold separately, P3-RTB); optiona_{… (read more)}	$1,443.00
Product Code : P3-08DA-2	8-channel Voltage output - 8-channel voltage analog output module, 16-bit resolution, +/-10 VDC, external 24 VDC required. Requires removable terminal block (sold separately, P3-RTB); optional ZIPL_{… (read more)}	$1,345.00
Product Code : P3-8AD4DA-1	P3-8AD4DA-1 Analog - Combination analog I/O module, 8-channel current sinking analog input, 0-20 mA; 4-channel current sourcing analog output, 4-20 mA; 16-bit resolution, external 24 VDC requ_{… (read more)}	$1,115.00
Product Code : P3-8AD4DA-2	P3-8AD4DA-2 Analog - Combination analog I/O module, 8-channel voltage analog input, 0-5 VDC and 0-10 VDC; 4-channel voltage analog output, 0-5 VDC and 0-10 VDC; 16-bit resolution, external 24_{… (read more)}	$1,149.00
Product Code : P3-04ADS	4-channel analog input module - 4-channel (channel-to-channel isolated), voltage/current analog input module, 16-bit resolution, hardware jumper selectable signal ranges of: +/- 10 VDC, 0-5 VDC, 0-10 VD_{… (read more)}	$1,342.00
Product Code : P3-08RTD	8-channel RTD input module - 8-channel RTD and resistance temperature input module, 16-bit resolution, supports RTD Types Pt100, Pt1000, jPt100, 10 Ohm Cu., 25 Ohm Cu., 120 Ohm Ni., and resistance ra_{… (read more)}	$1,084.00
Product Code : P3-08THM	8-channel THM thermo input - 8-channel THM, differential thermocouple input module, 16-bit resolution, supports Types J, E, K, R, S, T, B, N and C with optional burn-out detection, voltage ranges of _{… (read more)}	$1,366.00
Product Code : P3-550E	P3 CPU module - Productivity3000 CPU module, 50 MB user memory, real time clock/calendar, 4 x 10 character LCD display, RS-232 (RJ12) port with Modbus RTU Master/Slave and ASCII In/out p_{… (read more)}	$1,244.00
Product Code : P3-622	Productivity3000 CPU - Productivity3000 CPU, up to 50 MB ladder memory, 4 x 10 character LCD display, USB A storage, (2) Ethernet 10/100Base-T (RJ45), (1) RS-232/RS-485 (RJ12), (1) RS-232/RS-48_{… (read more)}	$1,125.00
Product Code : P3-RX	Ethernet remote I/O slave mod - Ethernet remote I/O slave module for Productivity3000 PAC, installs in the CPU slot of the first base in each remote base group. Includes: two serial communication ports:_{… (read more)}	$837.00
Product Code : P3-SCM	Serial Comms Mod 4 Port - 4-port serial communications module for Productivity3000, Ports 1, 2 and 3: RS-232C (RJ12) half or full duplex ports; Port 4: selectable between (1) RS-232C (RJ12) or (1)_{… (read more)}	$888.00
Product Code : P3-EX	Prod3000 Local I/O expansion - Productivity3000 local I/O expansion module, installs in the CPU slot of each expansion base and connects to the CPU, remote slave or previous expansion base with the P3-_{… (read more)}	$253.00
Product Code : P3-HSO	High Speed 1 Mhz Output module - High-speed pulse output module for Productivity3000 PAC, with two (2) independent output channels up to 1 MHz each, plus six (6) 5-24VDC general purpose discrete inputs a_{… (read more)}	$1,094.00
Product Code : P3-HSI	High Speed 1MHz Input Module - High-speed counter input module for Productivity3000 PAC, with two (2) independent input channels up to 1 MHz each, plus two (2) 5-24VDC general purpose discrete inputs a_{… (read more)}	$1,048.00
Product Code : P3-FUSE-2	Spare fuse P3-16TA/P3-06TR - Spare fuse for the following P3000 discrete output modules: P3-16TA, P3-06TR and P3-08TRS-1	$19.00
Product Code : P3-FUSE-1	Spare fuse P3-08TAS/P3-06TRS - Spare fuse for the following P3000 discrete output modules: P3-08TAS and P3-06TRS	$19.00
Product Code : USB-CBL-AB10	10ft standard USB 2.0 cable 3m - USB cable, 10 ft. (3.0 meter), Standard A plug to Standard B plug. Suitable for Productivity3000, C-more and Do-more programming and most USB devices.	$66.00
Product Code : USB-CBL-AB15	15ft/4.6m standard USB cable - USB cable, 15 ft. (4.6 meter), Standard A plug to Standard B plug. Suitable for Productivity3000, C-more and Do-more programming and most USB devices.	$76.00
Product Code : ZL-P3-CBL20-L	Productivity3000 ZIPLink Cable - ZIPLink cable used to connect Productivity 3000 PAC I/O modules (P3-08TD1S, P3-08TD2S, P3-16NA, P3-16ND3, P3-04ADS, P3-08AD, P3-16AD-1, P3-16AD-2, P3-04DA, P3-08DA-1, P3-_{… (read more)}	$104.00
Product Code : ZL-P3-CBL20-P	0.5M Product3000 ZIPLink Cable - ZIPLink cable that allows Productivity 3000 PAC I/O modules with 20-position terminal blocks to custom wire to 3rd party devices, 24 AWG, 0.5 meter (1.6 ft.) length	$101.00
Product Code : P3-08ND3S	8-point 12-24 VDC input 8 comm - Productivity3000 discrete input module, 8-point, 12-24 VDC, sinking/sourcing, 8 common(s), isolated, 1 point(s) per common. Requires removable terminal block (sold separa_{… (read more)}	$228.00
Product Code : P3-16ND3	16-point 12-24VDC input 4 comm - Productivity3000 discrete input module, 16-point, 12-24 VDC, sinking/sourcing, 4 common(s), isolated, 4 point(s) per common. Requires removable terminal block (sold separ_{… (read more)}	$344.00
Product Code : P3-32ND3	32-point 24VDC input 4 commons - Productivity3000 discrete input module, 32-point, 24 VDC, sinking/sourcing, 4 isolated common(s), 8 point(s) per common. Requires ZIPLink connector modules and pre-wired _{… (read more)}	$445.00
Product Code : P3-64ND3	64-point 24VDC input 8 commons - Productivity3000 discrete input module, 64-point, 24 VDC (+/-10%), sinking/sourcing, 8 common(s), isolated, 8 point(s) per common. No terminal block sold for this module;_{… (read more)}	$589.00
Product Code : P3-08NAS	8-point 100-240 VAC 8 commons - Productivity3000 discrete input module, 8-point, 120-240 VAC, 8 isolated common(s), 1 point(s) per common. Requires P3-RTB removable terminal block or ZIPLink pre-wired c_{… (read more)}	$282.00
Product Code : P3-16NA	16 point 100-240 VAC 4 commons - Productivity3000 discrete input module, 16-point, 100-240 VAC, 4 common(s), isolated, 4 point(s) per common. Requires removable terminal block (sold separately, P3-RTB); _{… (read more)}	$355.00
Product Code : P3-08TD1S	8-point 6-27VDC Sinking2A 4com - Productivity3000 discrete output module, 8-point, 6-24 VDC, sinking, 4 isolated common(s), 2 point(s) per common, 2A/point, 4A/common. Requires P3-RTB removable terminal _{… (read more)}	$338.00
Product Code : P3-08TD2S	8-point6-27VDC Sourcing2A 4com - Productivity3000 discrete output module, 8-point, 6-24 VDC, sourcing, 4 isolated common(s), 2 point(s) per common, 2A/point, 4A/common. Requires P3-RTB removable terminal_{… (read more)}	$348.00
Product Code : P3-16TD1	16-point 6-27VDC Sinking 0.5A - Productivity3000 discrete output module, 16-point, 6-24 VDC, sinking, 2 isolated common(s), 8 point(s) per common, 0.5A/point, 4A/common. Requires P3-RTB removable termin_{… (read more)}	$371.00
Product Code : P3-16TD2	16-point 6-27VDC Sourcing 0.5A - Productivity3000 discrete output module, 16-point, 6-24 VDC, sourcing, 2 isolated common(s), 8 point(s) per common, 0.5A/point, 4A/common. Requires P3-RTB removable termi_{… (read more)}	$379.00
Product Code : P3-32TD1	32-point 6-27VDC Sinking 0.3A - Productivity3000 discrete output module, 32-point, 6-24 VDC, sinking, 4 isolated common(s), 8 point(s) per common, 0.3A/point, 2.4A/common. Requires ZIPLink connector mod_{… (read more)}	$466.00
Product Code : P3-32TD2	32-point 20-30VDC Sourcing0.2A - Productivity3000 discrete output module, 32-point, 24 VDC, sourcing, 4 isolated common(s), 8 point(s) per common, 0.2A/point, 1.6A/common. Requires ZIPLink connector modu_{… (read more)}	$445.00
Product Code : P3-64TD1	64-point 6-27VDC Sinking 0.1A - Productivity3000 discrete output module, 64-point, 6-24 VDC, sinking, 8 isolated common(s), 8 point(s) per common, 0.1A/point, 0.8A/common. Requires ZIPLink connector mod_{… (read more)}	$659.00
Product Code : P3-64TD2	64-point20-30VDC Sourcing 0.1A - Productivity3000 discrete output module, 64-point, 24 VDC, sourcing, 8 isolated common(s), 8 point(s) per common, 0.1A/point, 0.8A/common. Requires ZIPLink connector modu_{… (read more)}	$599.00
Product Code : P3-08TAS	8-point 80-288VAC output - Productivity3000 discrete output module, 8-point, 120-240 VAC, 8 common(s), 8 isolated common(s), 1 point(s) per common, 1A @ 40 deg C, 0.7A @ 60 deg C. Requires P3-RTB r_{… (read more)}	$444.00
Product Code : P3-16TA	16-pint 80-288VAC output - Productivity3000 discrete output module, 16-point, 120-240 VAC, 2 isolated common(s), 8 point(s) per common, 0.5A/point, 4A/common. Requires P3-RTB removable terminal blo_{… (read more)}	$470.00
Product Code : P3-16TR	16-point 6-27VDC 6-240VAC - Productivity3000 relay output module, 16-point, 6-24 VDC/6-240 VAC, (16) Form A, 2 isolated common(s), 8 point(s) per common, 1.25A/point, 6.3A/common. Requires P3-RTB re_{… (read more)}	$401.00

Features of the P3-550E CPU

Memory: Up to 50MB total memory
Programming language: Ladder logic and Structured Text
System: Rack based
Maximum I/O Capacity: 7000 I/O points possible (using local and remote expansion)
Communications: Up to 7 comms ports including USB, Ethernet, RS-232, RS-485.

Numerous netwoking options built in, including serial and Ethernet, supporting many industry-standard protocols and remote devices
Real time clock/ Calendar
Battery included for the retention of the Time and Date along with any Tagname values that are set up as retentive
Built-in EtherNet/IP Scanner and Adapter functionality
MQTT support for easy IIoT/cloud networking
Hardware auto-discovery
LCD status displays on CPU and analog modules
System can be expanded with P3-RX or P3-EX module
Tag database and program documentation storage on-board the CPU
Secure Web Server for fast easy access to your data
Optional I/O terminal blocks or the popular ZipLink wiring solutions

p3000-cpu-tech-brief-diagram

Programmed with the Productivity Suite software that offers ladder logic and structured text programming, tag-name-based memory, and supreme device integration

• CPU, Remote & Expansion Modules

P3-550E High Performance CPU Module
The P3-550E has 50MB of memory and fast scan time (266MHz processor) - this CPU does the work of at least four or five pieces of hardware compared to other controllers. This high performance CPU has six built-in communication ports.
P3-EX Expansion Module
The P3-EX high-performance expansion module provides local I/O expansion to a CPU or Remote I/O. Includes 6-foot USB expansion cable.
P3-RX Remote Slave Module
The P3-RX is a lower cost full-featured, high-performance Remote Slave module (without the LCD display) and with four communications ports which support USB local expansion, Ethernet, and Serial devices. Up to 16 P3-RX Remote Slaves can be connected to a single P3-550 CPU remote I/O network.

Documentation

(AutomationDirect website) For current $AU please refer to our online store

Productivity 3000 Overview

Productivity 3000 Technical Specfications

ProductivitySuite Software Overview
